Today in this tutorial I am going to tell you How to calculate Cement, Sand and Aggregate Quantity in Concrete in very easy steps at Construction Sites.
Contents
Cement, Sand and Aggregate Quantity in Concrete
Here I have consider Concrete Volume (WET) = 1 Cubic Meter
Grade of Concrete Mix = M15 (Cement = 1 : Sand = 2 : Aggregate = 4)
Sum of the ratio of Cement, Sand & Aggregate = 1+2+4 = 7
First we have to find the Dry Volume of Concrete by Increasing the Wet Volume by 54 percent.
Dry Volume = Wet Volume x (54% of Wet Volume)
= 1 x (54 x 1 / 100) = 1.54 Cubic Meter
Now we have to find the quantity of Cement, Sand & Aggregate. Here I will show you the calculation of quantity in different units like Cubic Meter, KG, Bags, Cubic Feet.
CEMENT
1) Cubic Meter = Dry Volume x (Ratio of Cement / Sum of Total Ratio)
= 1.54 x (1 / 7) = 0.22 Cubic Meter
2) KG = Dry Volume x (Ratio of Cement / Sum of Total Ratio) x Density of Cement
= 1.54 x (1 / 7) x 1440 = 316.8 KG
3) Bags = We know, 50 KG = 1 Bag of Cement
316.8 KG = 316.8 / 50 = 6.336 Bags of Cement
4) Cubic Feet = If we multiply Number of Cement bags by 1.226, we get the value in Cubic Feet i.e. 6.336 x 1.226 = 7.77 Cubic Feet
- Steel Bar Weight Calculation At Site
- Quantity Of Tiles For Wall & Cladding
- Quantity Of Tiles For Flooring At Site
- Mix Design Of Concrete As Per IS 10262
- Calculate The Unit Weight of M.S Angle For Billing
- How To Calculate Volume of Trapezoidal Footing
- How to Calculate Concrete Volume For Slump Test
- Derivation of Volume Of Frustum For Slump Test
- What is 1.54 in Concrete
- How To Calculate Length Of Chord For Circle
- How To Calculate Weight Of Steel Bar
- How To Calculate Weight Of Mild Steel Plate
- How To Calculate Quantity Of Cement Sand water in Plaster
- Derivation Of (d²/162) – Unit Weight Of Bar
- Volume Of Different Shapes
- AREA OF DIFFERENT GEOMETRICAL SHAPES
- How To Calculate Cement, Sand And Aggregate Quantity In Concrete
- How Much Cubic Feet In One Bag Cement
SAND
1) Cubic Meter = Dry Volume x (Ratio of Sand / Sum of Total Ratio)
= 1.54 x (2 / 7) = 0.44 Cubic Meter
2) KG = Dry Volume x (Ratio of Sand / Sum of Total Ratio) x Density of Sand
= 1.54 x (2 / 7) x 1450 = 638 KG
[Density of Sand varies between 1450 – 1500 KG per Cubic Meter]
3) Cubic Feet = Dry Volume x (Ratio of Sand / Sum of Total Ratio) x 35.3147
= 1.54 x (2 / 7) x 35.3147 = 15.54 Cubic Feet
[NOTE : 1 Cubic Meter = 35.3147 Cubic Feet]
ALTERNATIVE : No. of Cement Bags x Value of one bag of cement in Cubic Feet x Ratio of Sand
= 6.336 x 1.226 x 2 = 15.54 Cubic Feet
AGGREGATE
1) Cubic Meter = Dry Volume x (Ratio of Aggregate / Sum of Total Ratio)
= 1.54 x (4 / 7) = 0.88 Cubic Meter
2) KG = Dry Volume x (Ratio of Aggregate / Sum of Total Ratio) x Density of Aggregate
= 1.54 x (4 / 7) x 1500 = 1320 KG
[Density of Aggregate varies between 1450 – 1550 KG per Cubic Meter]
3) Cubic Feet = Dry Volume x (Ratio of Aggregate / Sum of Total Ratio) x 35.3147
= 1.54 x (4 / 7) x 35.3147 = 31.07 Cubic Feet
[NOTE : 1 Cubic Meter = 35.3147 Cubic Feet]
ALTERNATIVE : No. of Cement Bags x Value of one bag of cement in Cubic Feet x Ratio of Aggregate
= 6.336 x 1.226 x 4 = 31.07 Cubic Feet
Below I Am Uploading My Hand Made Documents For You Only On Your Request, So That You Can Download It From Here. But One Thing Keep In Mind That This Is Only The Hand Made Notes.
If You Want Detailed Knowledge Then Watch My Video On YouTube Channel: Civil Learning Technology. I Am Telling This Because Many Important Points I Have Covered During Making Of Video, So If You Want To Know In Detail Then Watch My Video On YouTube Which is Given Below.
